AXI 2814/20 Cyclone KV840
  • AXI 2814/20 Cyclone KV840
  • AXI 2814/20 Cyclone KV840
  • AXI 2814/20 Cyclone KV840

AXI 2814/20 Cyclone KV840

137,04 €
Su PVM
Pristatysime per 7-14 darbo dienų
Atsiskaitymas visa paypal mastercard
message Klauskite apie šią prekę

Klauskite apie šią prekę

AXI 2814/20 Cyclone KV840

AXI 2814/20 Cyclone KV840

* Privalomi laukai

  Atšaukti

Supply voltage LiXX cells: 2 - 3 ; RPM/V [RPM/min/V]: 840 ; Nr. of turns: 20 ; Internal resistance [mOhm]: 145 ; No load current [mA]: 600 ; max. effenciency [%]: 85 ; Max. efficiency current (η>75%) [A]: 8 - 17 ; Max. peak current (60 s) [A]: 28 ; Max. power [W]: 365 ; Diameter [mm]: 40 ; Lenght [mm]: 63 ; Shaft diameter [mm]: 5 ; Weight [g]: 164 ; Nr. of poles: 14 ; Timming [°]: 15 - 25 ; ESC [A] : 30 - 40 ; Sailplane up to Weight [g]: 1900

Powering LiXX cells2 - 3
RPM/V [ot./min/V]840
Turn count20
Internal resistance [mOhm]145
Open-circuit current [mA]600
Max. efficiency [%]85
Max. efficiency current (η>75%) [A]8 - 17
Max. peak current (60 s) [A]28
Max. power [W]365
Diameter [mm]40
Length [mm]63
Shaft diameter [mm]5
Weight [g]164
Poles count14
Timing [°]15 - 25
ESC [A] 30 - 40
Weight of glider (up-to) [g]1900
Doporučená vrtule2S: 13x8"
Doporučená vrtule3S: 12x6,5"
AXI
3EL105702
