AXI 2820/12 Cyclone KV990
  • AXI 2820/12 Cyclone KV990
  • AXI 2820/12 Cyclone KV990
  • AXI 2820/12 Cyclone KV990

AXI 2820/12 Cyclone KV990

157,34 €
Su PVM
Pristatysime per 7-14 darbo dienų
Atsiskaitymas visa paypal mastercard
message Klauskite apie šią prekę

Klauskite apie šią prekę

AXI 2820/12 Cyclone KV990

AXI 2820/12 Cyclone KV990

* Privalomi laukai

  Atšaukti

Supply voltage LiXX cells: 2 - 3 ; RPM/V [RPM/min/V]: 990 ; Nr. of turns: 12 ; Internal resistance [mOhm]: 59 ; No load current [A]: 1.6 ; max. effenciency [%]: 85 ; Max. efficiency current (η>76%) [A]: 15 - 25 ; Max. peak current (60 s) [A]: 40 ; Max. power [W]: 660 ; Diameter [mm]: 40 ; Lenght [mm]: 69 ; Shaft diameter [mm]: 5 ; Weight [g]: 197 ; Nr. of poles: 14 ; Timming [°]: 15 - 25 ; ESC [A] : 40 - 60 ; Sailplane up to Weight [g]: 2400

Powering LiXX cells2 - 3
RPM/V [ot./min/V]990
Turn count12
Internal resistance [mOhm]59
Open-circuit current [A]1.6
Max. efficiency [%]85
Max. efficiency current (η>76%) [A]15 - 25
Max. peak current (60 s) [A]40
Max. power [W]660
Diameter [mm]40
Length [mm]69
Shaft diameter [mm]5
Weight [g]197
Poles count14
Timing [°]15 - 25
ESC [A] 40 - 60
Weight of glider (up-to) [g]2400
Doporučená vrtule3S: 12x6,5"
AXI
3EL105703
