AXI 5330/F3A V2 brushless
Atsiliepimai
Pateikti atsiliepimą
Supply voltage LiXX cells: 8 - 10 ; RPM/V [RPM/min/V]: 235 ; Internal resistance [mOhm]: 45 ; No load current [A]: 1.7 ; max. effenciency [%]: 93 ; Max. efficiency current (η>85%) [A]: 23 - 57 ; Max. peak current (60 s) [A]: 73 ; Max. power [W]: 2780 ; Diameter [mm]: 63 ; Lenght [mm]: 65.5 ; Shaft diameter [mm]: 8 ; Weight [g]: 672 ; Nr. of poles: 14 ; Timming [°]: 15 - 25 ; ESC [A] : 90 - 120 ; Sailplane up to Weight [g]: 15000 ; Trainer up to Weight [g]: 8000 ; Acrobat up to Weight (F3A) [g]: 5500 ; 3d up to Weight [g]: 4800
| Powering LiXX cells | 8 - 10 |
| RPM/V [ot./min/V] | 235 |
| Internal resistance [mOhm] | 45 |
| Open-circuit current [A] | 1.7 |
| Max. efficiency [%] | 93 |
| Max. efficiency current (η>85%) [A] | 23 - 57 |
| Max. peak current (60 s) [A] | 73 |
| Max. power [W] | 2780 |
| Diameter [mm] | 63 |
| Length [mm] | 65.5 |
| Shaft diameter [mm] | 8 |
| Weight [g] | 672 |
| Poles count | 14 |
| Timing [°] | 15 - 25 |
| ESC [A] | 90 - 120 |
| Weight of glider (up-to) [g] | 15000 |
| Weight of trainer (up-to) [g] | 8000 |
| Weight of acrobat (up-to) (F3A) [g] | 5500 |
| Weight of 3D (up-to) [g] | 4800 |
| Doporučená vrtule | 10S: 20x10-13", 22x8" |
