SG-1213MG micro HiVolt digital glider servo (4,5kg-0,17s/60)

The Savox SG-1213MG micro digital servo has been designed for glider models, especially in the F3K category. Thanks to its unique design with the motor protruding from the case, it offers a great size to torque ratio.

Features:

• Metal gear train ensures durability and longevity.
• Aluminum middle case allows for cooler operating temperatures.
• Ideal for gliders
• NEW: SSR mode compatible
• NEW: SOFT START
• Hi-Volt

Specifications:

• Torque @6.0v - 3.5kg
• Torque @7,4v - 4.5kg
• Speed @6.0v - 0.21 sec/60 deg
• Speed @7,4v - 0.17 sec/60 deg
• Dimensions L x W x H (mm):23.0 x 9.2 x 24.5
• Weight: 13.5g

Technical Details

• Operating Temperature: (-10° - 50°C)
• Wire Length: 250 ± 5mm
• Output Gear Spline: 21 Tooth
• Bearings: 2BB
• Operating Travel: 90° (1000 → 2000 µ second)
• Neutral Position: 1500 µ second
• Pulse Width Range: 750 → 2250 µ second
• Maximum Travel: Appx 145° (750 → 2250 µ second)
• Refresh Rate: 240 Hz
• Motor Type: Coreless
